Fujitsu ASY50-KM Design & Technical Manual

Model: ASYG18KMTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
-5.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
0.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
5.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
10.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
15.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
20.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
25.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
30.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
35.0 4.85 3.27 5.48 3.73 5.78 4.30 6.19 4.83 6.62 5.28 6.82 6.05
40.0 3.59 1.79 4.06 2.04 4.28 2.35 4.58 2.64 4.90 2.89 5.05 3.31
46.0 2.33 0.75 2.63 0.86 2.78 0.99 2.97 1.11 3.18 1.22 3.27 1.39
Model: ASYG22KMTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
-5.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
0.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
5.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
10.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
15.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
20.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
25.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
30.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
35.0 6.12 3.93 6.91 4.48 7.29 5.16 7.80 5.80 8.34 6.34 8.60 7.27
40.0 4.53 2.15 5.11 2.45 5.39 2.83 5.77 3.17 6.17 3.47 6.36 3.98
46.0 2.94 0.91 3.32 1.03 3.50 1.19 3.74 1.34 4.00 1.46 4.13 1.67
Model: ASYG24KMTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
-5.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
0.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
5.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
10.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
15.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
20.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
25.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
30.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
35.0 6.68 4.31 7.55 4.92 7.96 5.66 8.52 6.36 9.11 6.96 9.39 7.97
40.0 4.94 2.36 5.59 2.69 5.89 3.10 6.30 3.48 6.74 3.81 6.95 4.36
46.0 3.21 0.99 3.62 1.13 3.82 1.30 4.09 1.47 4.37 1.60 4.51 1.84
- 497 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
