En-3
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 POWER Switch
3 MANUAL AUTO button
4 Remote Control Signal Receiver
5 Indicator Lamps (Fig. 3)
6 OPERATION Indicator Lamp (red)
7 TIMER Indicator Lamp (green)
● If the TIMER indicator Lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 14 Auto Restart).
8 SWING Indicator Lamp (orange)
9 Intake Grille (Fig. 4)
0 Air Filter
A Air Flow Direction Louver
B Right-Left Louvers
(behind Air Flow Direction Louver)
C Drain Hose
D Power Supply Plug
E Power Supply Cord
F Air Cleaning Filter (optional)
Fig. 5 Outdoor Unit
G Intake Port
H Outlet Port
I Pipe Unit
J Drain port (bottom)
Fig. 6 Remote Control Unit
K SLEEP button
L MASTER CONTROL button
M SET TEMP./SET TIME buttons ( )
N Signal Transmitter
O TIMER button
P FAN CONTROL button
Q START/STOP button
R AIR FLOW DIRECTION button
S SWING LOUVER button
Rear side (Fig. 7)
T TIME ADJUST button
U ACL button
(located inside battery compartment)
V TEST RUN button
● This button is used when installing the
conditioner, and should not be used un-
der normal conditions, as it will cause the
air conditioner’s thermostat function to op-
erate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the Indoor Unit’s OPERA-
TION Indicator Lamp and TIMER Indicator
Lamp will begin to flash simultaneously.
● To stop the test operation mode, either
press the TEST RUN button once again, or
press the START/STOP button to stop the
air conditioner.
W Remote Control Unit Display (Fig. 8)
X Transmit Indicator
Y Clock Display
Z Operating Mode Display
[ Timer Mode Display
\ Fan Speed Display
] Temperature Set Display
_ Timer Set Indicator
a Temperature Set Indicator
NAME OF PARTS
●
Refer to the fold-out page on the cover.
To Next Page
