REFRIGERANT SYSTEM DIAGRAM
Models : ASY9LSACW / AOY9LSACW
ASY12LSACW / AOY12LSACW
(2 pass)
(2 pass)
Indoor heat exchanger
Outdoor heat exchanger
Capillary
tube
Pulse motor valve
2way-valve
3way-valve
Muffler
Compressor
Accumulator
4way-valve
Strainer
Dryer
4
2004.10.07
4
6
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Specifications
2
Electrical Data
2
Dimensions
3
Indoor Unit
4
Outdoor Unit
4
Circuit Diagram
4
Refrigerant System Diagram
5
Self-Diagnosis Function Table (Flashing LED Display)
6
Error Contents
6
Indoor Printed Circuit Board
8
Pcb Circuit Diagram
8
Outdoor Printed Circuit Board
9
Disassembly Illustration
10
Parts List
13
Standard Accessories
15
