Fujitsu ASYG07KGTE User Manual

2-2. Outdoor unit
¢
Models: AOYG07KGCA, AOYG09KGCA, AOYG12KGCA, and
AOYG14KGCA
Unit: mm
580
109
330 353
Pitch of bolts for installation
Pitch of bolts for installation
Top view
4- M1 0 hole
Side viewSide view
Front view
799 68 29016
33 30
19
542
20
Airflow
Bottom view Side view (Valve part)
37
399
Drain port Ø42
184
120
180
2-2. Outdoor unit - (01-6) - 2. Dimensions
