Front panel total assy
Front panel B
Panel cover
Front panel
22
21
23
24
Item no. Part no. Part name Service part
21 9387473018 Air filter ♦
22 9323546004 Intake grille assy ♦
23 9333719009 Grille clamper L ♦
23 9333704005 Grille clamper R ♦
3-4. Wall mounted type - (02-41) - 3. Indoor unit parts list
