INDOOR UNIT
Control box
12
Terminal 9900720001
Main PCB (ASYG09LLCC) 9709170182
13
Earth terminal
Control Box11
Cover shield
9332542004
Box shield assy
12
Main PCB (ASYG07LLCC) 970917017512
Main PCB (ASYG12LLCC) 970917019912
15 Room Thermistor Holder 9316895003
Ref. Description Part number
14
-- Thermistor Assy 9900714024
Display Assy 9709173015
2013.09.30
12
11
15
14
13
