46
15
41
Evaporator Total Assy (07, 09)
9316893085
42 Evaporator Total Assy (12) 9316893092
46 Rear Bracket 9332540017
44
43
9332538007
45 Evaporator Holder L
Evaporator Holder R
9332539004
Joint Pipe Assy (07, 09)
Earth Terminal
9332609004
43 Joint Pipe Assy (12) 9332608007
47 Filter Guide 9332541007
Ref. Description Part number
2013.09.30
41
43
42
INDOOR UNIT
Evaporator
ASYG07LLCC
ASYG09LLCC
ASYG12LLCC
44
45
47
