PARTS
INDOOR UNIT
ASYG07KGTA
ASYG09KGTA
ASYG12KGTA
ASYG14KGTA
2017.07.04 11
3 Bracket panel 9387480009
4 Electric filter holder 9332911008
5 Air clean filter assy 9317250009
1
Remote control (no brand)
9382108045
2 Remote control holder 9318912005
Ref. Description Part number
5
4
3
1
2
