INDOOR UNIT
ASYG07KGTA
ASYG09KGTA
ASYG12KGTA
ASYG14KGTA
2017.08.29 12
11
12
14
Front panel total assy
Wire cover assy
9387596007
Screw cap 9387476002
Ref. Description Part number
Under cover L 9387477009
13 Under cover R 9387478006
14
11
12
13
11
