54
55
INDOOR UNIT
ASYG07KGTA
ASYG09KGTA
ASYG12KGTA
ASYG14KGTA
Control box
16
Terminal
Display case assy
Front panel
cover B assy
930648904552
Control box
Main PCB (ASYG07)
971078201551
Main PCB (ASYG09)
971078202251
Ref. Description Part number
53
Box shield
55 Pyroelectric sensor 9317755061
Display assy 9710858017
54 Indicato PCB
Wi-Fi holder
PWB
holder A
9710786013
2017.08.29
51
53
52
Main PCB (ASYG12)
971078203951
Main PCB (ASYG14)
971078204651
