INDOOR UNIT
ASYG07KGTA
ASYG09KGTA
ASYG12KGTA
ASYG14KGTA
17
64
61
Step motor
Cable guide
Base total assy
Step motor
holder assy
9900384241
63 Drain pan total assy 9387590005
Evaporator total assy (07, 09) 9387593006
Ref. Description Part number
2017.09.07
Step
motor
holder
62 Evaporator total assy (12, 14) 9387593013
63
61
64
62
