INDOOR UNIT
ASYG07KGTA
ASYG09KGTA
ASYG12KGTA
ASYG14KGTA
Base total assy
Motor cover assy
Fan motor
Motor case
Brushless motor (07, 09) 9603569013
Bearing D assy
9387055016
Motor cover assy
Base assy
73
Crossflow fan assy
9333628004
71
72
Ref. Description Part number
182017.08.28
73
72
71
Brushless motor (12, 14) 960357201371
