DIMENSIONS
2013.01.15 2
OUTDOOR UNIT
540 mm
290 mm790 mm
540 mm
260 mm
202 mm790 mm
INDOOR UNIT
Drain pipe diameter
O.D 15.8 to 16.7 mm
Liquid pipe diameter : 6.35 mm
Gas pipe diameter : 9.52 mm
