OUTDOOR UNIT
AOYG09LLC
2012.03.05 21
32 Compressor Assy 9332603002
36 3 way Valve Assy 9332653007
38 2 way Valve Assy 9332652000
33 Solenoid 9970119019
31 Condenser Total Assy 9332594003
35 Muffler 9317398008
34 4 way Valve Assy 9332602005
37 Capillary Assy 9332601008
Ref. Description Part number
32
37
31
35
36
34
38
33
