Model: ABYG18LVTB (Under ceiling)
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
10
Unit: m/s
(m)
0
1
1
2
2
(m)
0123 4567 89
0.250.51.02.0
Top view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Left & Right
10
(m)
01 2 34 5 67 89
Unit: m/s(m)
0
1
1
2
2
3
4
5
3
4
5
0.25
0.25
0.5
0.5
1.0
1.0
2.0
2.0
Side view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
10
(m)
012
3
456 789
(m)
3
1
2
Unit: m/s
0.250.5
1.0
2.0
Side view
Vertical airflow direction louver: Center
Horizontal airflow direction louver: Center
0.25
0.5
1.0
2.0
10
(m)
012
3
456 789
(m)
3
1
2
Unit: m/s
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
(m)
0
12
3
456 7
(m)
3
1
2
Unit: m/s
0.25
0.5
1.0
2.0
- 87 -
MULTI TYPE 5, 6 ROOMS TYPE
