DIMENSIONS
unit : mm
282
185
870
2011.05.06 2
INDOOR UNIT
Drain pipe diameter
16.2 mm
Liquid pipe diameter : 6.35 mm
Gas pipe diameter : 9.52 mm
OUTDOOR UNIT
540
290790
540
