Fujitsu ASYG12LMCA

51
49
47
43
42 42
45
50
41
44
48
46
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LMCA
ASYG09LMCA
ASYG12LMCA
ASYG14LMCA
Casing assy
85
Fan Guard 9332905007
50
51
Step Motor 9900790004
46
Drain Hose Assy 9316904002
47
Step Motor 990079001148
Drain Cap 9316177017
41
Casing Cover B 9332908008
43
Casing Cover F 9332909005
42
R and L Louver A 9332891003
Casing 9332890006
Cable Guide 9332903003
Motor Holder L/R 9332859003
49
44
45
Ref. Description Part number
2013.04.19
