Fujitsu ASYG12LMCA - Page 75

47
43
44
48
45
56
57
46
49
50
58
42
53
55
51
52 54
41
Parts number DescriptionRef
41 Casing Assy (24)
42
Casing Cover B43
Casing Cover L44
Casing Cover R45
Casing Cover F46
Drain Cap
9315331045
41 Casing Assy (18) 9315331038
9315016010
9315017017
9315018014
9315019011
9367677009
Bush B49
Spacer B50
R and L Louver58
9312156016
9312441013
931199701647
Drain Hose Assy 931576901548
Casing 9314993015
Parts number DescriptionRef
Louver U51
Louver Z52
Diffuser U
9315000019
9315001016
931500201353
Diffuser Z 9315003010
Spring C 9314142017
Piller A 9315009012
Joint B 9315006011
54
55
57
56
Fan Guard 9305751051-
Fan Guard Holder Right 9315814012-
Fan Guard Holder Left 9315815019-
882013.04.25
INDOOR UNIT
WALL MOUNTED
ASYG18LFCA
ASYG24LFCA
ASYG24LFCC
