2-6. Floor type
¢
Models: AGYG09KVCA, AGYG12KVCA, and AGYG14KVCA
600
200
Side view
Front view
740
Unit: mm
Installation space
100 or more
80 or more
80 or more
150 or below from the floor
50 or more
2-6. Floor type - (01-33) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
