14-11. Wired remote controller (UTY-RCRYZ1: Optional part)
¢
Overview
b
c
a
d
e
f
g
a Display panel
b MODE button
c Menu button
d
, buttons (Set temperature buttons)
e FAN button
f On/off button
g Wireless remote controller signal receiving section
