Fujitsu ASYG14KMTB Design & Technical Manual


Ceiling type
Model: ABYG18KRTA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
-5.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
0.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
5.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
10.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
15.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
20.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
25.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
30.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
35.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
40.0 3.93 2.03 4.44 2.31 4.68 2.66 5.02 2.99 5.36 3.27 5.53 3.75
46.0 3.11 1.27 3.52 1.45 3.71 1.67 3.97 1.87 4.25 2.05 4.38 2.35
Model: ABYG22KRTA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
-5.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
0.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
5.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
10.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
15.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
20.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
25.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
30.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
35.0 6.01 3.73 6.79 4.25 7.15 4.90 7.66 5.50 8.19 6.02 8.44 6.90
40.0 4.97 2.56 5.62 2.91 5.92 3.35 6.34 3.77 6.78 4.12 6.99 4.72
46.0 3.94 1.60 4.45 1.83 4.69 2.10 5.02 2.36 5.37 2.58 5.53 2.96
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
