Fujitsu ASYG14KMTB Design & Technical Manual

Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
46
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
45
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
44
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
43
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
42
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
41
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
40
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
39
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
38
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
- 509 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5

Fujitsu ASYG14KMTB Specifications

General

Brand	Fujitsu
Model	ASYG14KMTB
Category	Air Conditioner
Language	English
