En-8
Cleaning Ion deodorization lter and
Replacing Apple-catechin lter
1. Remove the air lters. Refer to steps 1 ~ 2
of “Cleaning air
lter”.
2. Remove the air cleaning lters from the air cleaning lter
holder.
Air cleaning lter
Air cleaning lter frame
3. Flush the Ion deodorization lter (light blue) with high-
pressure hot water until the surface of the lters are covered
with water.
4. Wash the Ion deodorization lter with diluent neutral
detergent.
Do not ream or rub, otherwise the deodorizing effect may decrease.
5. Rinse the Ion deodorization lter with water ow.
6. Dry the Ion deodorization lter in shade.
7. Remove the Apple-catechin lter (light green) from the air
cleaning lter holder.
8. Set the new or washed air cleaning lters into the air
cleaning lter frames.
NOTES: Use the Apple-catechin lter as soon as possible after opening
the package. The air cleaning effect decreases when the lters
are left in the opened package.
9. Install the air cleaning lter holders to the air lters.
Engage the 4 hooks at the rear of the air cleaning lter frame with
the latch at both ends of the air lter.
* Take care that the air cleaning lter does not project beyond the
frame.
Hook (4 places at the rear)
Latch (4 places)
NOTES: Take care that the air cleaning lter does not project
beyond the frame.
10. Replace the air lters and close the intake grille. Refer to
steps 4 ~ 5 of “Cleaning air lter”.
Replacing Ion deodorization lter
1. Remove the air lters. Refer to steps 1 ~ 2
of “Cleaning air
lter”.
2. Remove the Ion deodorization lter (light blue) from the air
cleaning lter holder.
3. Install the new Ion deodorizing lter.
Removing and installing intake grille
■
Removing intake grille
1. Open the intake grille until it snaps.
2. Pull the mounting shafts while keeping the intake grille in a
horizontal position.
■
Installing intake grille
1. While holding the intake grille horizontal, set the left and
right mounting shafts into the pillow blocks at the top of the
front panel.
Insert the shaft until it snaps to latch each shaft properly.
2. Close the intake grille.
3. Press 4 places on the intake grille to close it completely.
After extended non-use of the unit
If you have shut down the indoor unit for 1 month or more, perform the
Fan mode operation for half a day to dry the internal parts thoroughly
before the normal operation.
Additional inspection
After long period of use, accumulated dust inside the indoor unit may
reduce the performance even if you have maintained the unit properly.
In such a case, a product inspection is recommended.
For more information, consult authorized service personnel.
Filter indicator reset (Special setting)
This function can be used if set correctly during installation. Please
consult authorized service personnel in order to use this function.
Clean the air lter when the indicator lamp show the
following:
Indicator lamp Blinking pattern
Blinks 3 times, at intervals of 21 seconds
After cleaning, reset the lter indicator by pushing
on the
indoor unit for 2 seconds or less.
9387858020_OM.indb 8 2/8/2019 1:53:16 PM
