Fujitsu AUG54AGB3W - Outline and Dimensions

2003.06.11
- 2 -
OUTLINE AND DIMENSIONS
1,152
23
940
370
Unit : mm
30
296
750
940
60
(Drain pipe)
120
285
(Small pipe)
150 (Large pipe)
940
298.5
305.5 248.5
60
(Drain pipe)
120
250
(Small pipe) 150 (Large pipe)
298.5
305.5 248.5
Drain Inside Dia. 32
Outside Dia. 37
750
