Model: ASYG18KMTB

Part name Exterior Qty Part name Exterior Qty

Operation manual 1

Self-tapping screw

(large)

Installation manual 1

Self-tapping screw

(small)

Remote controller 1 Battery 2

Remote controller

holder

1 Filter holder 2

Cloth tape 1 Air cleaning filters 1

Wall hook bracket 1
