16
14
15
11
12
13
Item no. Part no. Part name Service part
11
9710995965 Main PCB (For 07 model) ♦
9710995743 Main PCB (For 09 model) ♦
9710995750 Main PCB (For 12 model) ♦
9710995705 Main PCB (For 14 model) ♦
9710995767 Main PCB (For 18 model) ♦
12 0600063023 Holder ♦
13 9710019005 Communication PCB ♦
14 9710661006 Power supply PCB ♦
15 9900568009 Terminal ♦
16 9900896003 Terminal ♦
3-1. Compact cassette type - (02-5) - 3. Indoor unit parts list
