Fujitsu AUXG14KVLA Design & Technical Manual

Unit: mm
• Distance between the ceiling and the unit is from 20 to 300:
Choose one of these methods to set up the maintenance access.
850
1,100
Pattern A
Pattern B
50
Maintenance access
450100 to 200
1,000
450 125 5050700
Air
Air
Air
Air
Control box
1,600 or more
850
50
1,000
Control box
Bottom view
- 47 -
4-4. Medium static pressure duct type
4. Dimensions
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
