OUTDOOR UNIT
AOY_12LA_L
AOY_14LA_L
AOY_18LA_L
Unit : mm
Top view
Front view
Side view
Bottom view
Drain pipe
mounting place
( 20)
189
177
347
540
300
66
790
121
578
320
10
184
4- 10mm hole
Air flow
2009.06.18
