Interfaces and connectors
Interfaces and connectors
The lo cation of the interfaces and connectors of your mainboard is specified
at the beginning of the manual.
The compone nts a n d connectors marked are no t nece ssarily present on the mainboard.
External ports
The location of the external connections of your mainboard is specified at the beg inning of the manual.
PS/2 k eyb oard port, purple (optional) PS/2 mouse port, green (optional)
LAN port (RJ-45)
Microphone port, pink
Audio input (Line in), light blue USB – Universal Serial B us, black
Audio output (Line o ut), light green VGA, blue
Serial interface, turquoise
The external U SB ports on the back may be loaded with a maximum of 2A between them.
Graphics controller
• Intel GMA 3000
• 256 Mbyte video memory
• Support of ADD2 cards (single and dual DVI adapter card)
Resolution ( colour depth up to 32 bits/pixel) Frequency
1024 x 768 (recommended / max*) 120 / 2 00 Hz
1280 x 1024 (recommended / max*) 100 / 120 Hz
1600 x 1200 (recommended / max*) 85 / 120 Hz
1440 x 900 Widescre en TFT (VGA / DVI) x / x
1680 x 1050 Widescreen TFT (VGA / DVI) x / x
1920 x 1200 Widescreen TFT (VGA / DVI) x / x
* maximum video rate for graphics configuration. The video quality may de teriorat e
if the maximum configuration is used.
2 - English A26361-D2317-Z110-1-8N19, edition 2
