Installing/removing processor( wit h heat sink)
Installing/removing processor
(with heat sink)
Disconnect the system completely from the mains voltage before performing any of the
tasks described below. Details are contained in your systems’ operating manual.
Technical data
• Intel Pentium 4, Intel Pentium D or Intel Core
TM
2 Duo with 533/800/1066 MHz
front side bus (max. 95 W) in th e LGA775 design
• A current list of the processors supported by this mainboard is available on the
Internet at: "www.fujitsu-siemens.com/mainboards".
Never touch the underside of the processor. Eve n minor soiling such as grease
from the skin can impair the processor’s operation or destroy the processor.
Place the processor in the socket with extre me care, as the spring contacts
of the socket are very delicate and must not be bent.
If one or more spring contacts are bent, do not insert the processor as it may be
damaged by doing so. Please contact the responsible vendor.
A26361-D2317-Z110-1-8N19, edition 2 English - 3
