Brief descript ion of mainboard
Installing/removing the processor
Disconnect the system from the mains voltage before performing a ny of the tasks
described b elow. Details are contained in the operat ing m anual of you r system.
Technical data
• Socket LGA 775, max. 130 W; Intel® Core 2 Quad Processors 1333/1066 MHz FSB;
Intel® C ore 2 DUO Processors 1333/1066/800 MHz FSB, Intel® Pentium Dual Core E2xxx
Processors 800 MHz F SB, Intel® Celeron® Processors 4xx 80 0 MHz FSB
• A current list of the processors supported by this mainboard is available on the
Internet at: "
http://ts.fujitsu.com/mainb oards".
Never touch the underside of the processor. Even minor soiling such as grease
from the skin can impair the processor’s operation or destroy the processor.
Place th e processor in the socket with extreme care, as the spring contacts
of t he socket a re very delicate and must not be be nt.
If one or more spring contacts are bent , on no account insert the processor as it
may b e damaged by doing so. Please contact the responsible vendor.
2 - English A26361-D2608-Z211-1-8N19, edition 1
