Fujitsu D2608 - Mechanical Slots and IRQ Mapping; PCI and PCIe Slot IRQ Table

Brief descript ion of mainboard
Mechanical slo t
PCI INT LINE 1 (A) 2 (B) 3 (C) 4 (D) 5 (E) 6 (F) 7 (G) 8 (H)
PCI
#1 Slot 7
--
DA
-
B
C
-
#2 Slot 6
--
AB
-
C
D
-
#3 Slot 3
-------
x
PCIe x16
Slot 2
AB
C
D
-
Slot 4
--
DC
-
BA
-
PCIe X1
--
C
D
-
AB
-
PCIe X4
--
x
-
Use first PCI/PCI Express slots that have a s ingle PCI IRQ Line (no IRQ sharing). If you
must use another PCI/PCI Express slot with IRQ sharing, ch eck whether the expansion card
properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all
cards and components on this PCI IRQ Line must also support IRQ sharing.
6 - English A26361-D2608-Z211-1-8N19, edition 1
