Brief description of the mainboard
Brief description of the mainb
oard
Information about boards
Be sure to observe the following for boards with ESD:
• You must always discharge static build up (e.g. by touching a grounded object)
before working .
• The equipment and tools you use must be free of static charges.
• Remove the power plug from the mains supply before inserting or removing
boards containing ESDs.
• Always hold boa rds by their edges.
• Never touch pins or c onductors on the board.
An overview of the features is provided in the data sheet.
Special features
Your mainboard is available in different configuration levels. Depending on the configuration,
your mainboard is equipped with or supports special features.
This manual describes the most important properties of this mainboard.
Additional information on mainboa rds is contained in the "Basic information on mainboard" manual
on the "User Documenta tion" or "OEM Mainboard" CDs, or on the Internet.
Ports and connectors
The location of the ports a
nd connectors of your mainboard is specified at the beginning of the manual.
The components and connect
ors m arked are not necessarily present on the mainboard.
External ports
The location of th e extern
al ports of your m a inboard is specifie d at the beginning of the manual.
PS/2 keyboard port, purple (optional) PS/2 mouse port, green (optional)
LAN port (RJ-45)
Microphone jack, pink
Audio input (Line in), light blue USB – Universal Serial B us, black
Audio output (Line out), l
ight green
VGA, blue
Serial interface, turquo
ise
The external USB ports on the back may be loaded with up to max. 2A in total.
A26361-D2610-Z110-1-8N19, edition 1 English - 1
