Brief description of the mainboard
Installing/removing processor (with heat sink)
Disconnect the system from the mains voltage before performing any of the tasks
described below. Details are contained in the operating manual of your system.
Technical data
• Intel Core Duo with 800 or 1066 MHz front side bus in the LG A775 design (FMB06-65W )
• Intel Pentium 4 / Pentium D with 533/800 MHz front side bus (FMB05A,
max. 95 W) in LGA775 design
• Intel Celeron D with 533 MH z front side bu s in the LGA775 design
• A current list of the processors supported by this mainboard is a vailable on the
Internet at: "
www.fujitsu-siemen s.com/mainboards".
Never touch the underside of the processor. Even minor soiling such as grease
from the skin can impair the processor’s operation or destroy the processor.
Place the processo r in the socket with extreme care, as the spring contacts
of the socket are very delicate and must not be bent.
If one or more spring contacts are bent, do not insert the processor in any case as
it may be damaged by d oing so. Please contact the responsible vendor.
2 - English A26361-D2610-Z110-1-8N19, edition 1
