Internal connectors and slo ts
External connectors rear
USB - dual channel
1
2
1 = VCC C
2 = VCC D
3 = Data negative C
4 = Data negative D
5=
6= Data positive D
Data positive C
7 = GND
8 = GND
Optionale Komponenten / Optional components
9= Key
10 = Not connected
A26361-D2703-Z240-1-8N19
PCI
USB
Module 2 Channel B
Buzzer
CF
BAT
PWSW
Intru
sio
n
External connectors front
D2703-A
