Fujitsu D2703 User Manual

Internal connectors and slots
External connectors rear
USB - dual channel
1
2
1 = VCC C
2 = VCC D
3 = Data negati ve C
4 = Data negati ve D
5=
6 = Data positi ve D
Data positi ve C
7 = GND
8 = GND
Optionale Komponenten / Optional components
9= Key
10 = Not connected
A26361-D2703-Z241-1-8N19
PCI
PWR
USB
Module 2 Channel B
Buzzer
COM 2
Front Audio
Fan 2
Fan 3
Drive PWR
Module 1 Channel A
SATA2
SATA0 SATA1
SATA3
USB
PCI Express x1
SPDIF
Battery
LVDS
Backlight
FireWire
Feature Con
CF Card
Front panel
D
2703-S
IDE
Fan 1
