30 Technical Manual D2759 (TX150 S7)
Connectors and indicators Features
No. Print Description
1 ATX 12V1 Power supply connector ATX12V1
2 PC98 Power supply connector PC98
3 ATX PWR1 Power supply connector ATXPWR1
4 SATA MLC SATA MLC connector (4 port)
5 Frontpanel Front panel connector
6 USB2 AUX USB 2 connector
7 USB1 AUX USB 1 connector
8 SATA 6 SATA 6 connector
9 SATA 5 SATA 5 connector
10 USB Front Triple USB connector for USB on the front side
11 TPM Connector for TPM
12 SMB1 I
2
C signal connector SMB1
13 Intrusion Intrusion connector
14 USB stick USB stick connector
15 USB SSD Connector for USB Flash Module (UFM)
16 HDD Activity Connector for HDD activity LED
17 Reset Connector for RESET switch
18 Serial 2 Connector for second serial interface
19 FAN1 SYS Connector for system fan 1
