Advanced Men u – A dvan ced system confi
guration
Peripheral confi guration – Ports and controllers
Peripheralco n figurationPortController
Opens the submenu used to adjust settings for ports and controllers.
Peripheral Configuration
Item Specific Help Serial 1:
[Auto]
[Enabled]
Configure serial port
using options
[Disabled]
No configuration
[Enabled]
User configuration
[Auto]
BIOS or OS chooses
configuration
Audio Controller:
[Enabled]
LAN Remote Boot:
[Enabled]
Diskette Controller:
USB Devices:
USB Ports:
[Enabled]
[All]
Serial 2:
[Disabled]
[Disabled]
Parallel port:
[Enabled]
USB Host Controller:
USB BIOS Hot-Plug:
[Enabled]
Beep Volume:
[High]
Example showing the Peripheral Configuration menu
Serial 1/Serial 2 – S erial ports
This field sel
ects the address and the interrupt used to access the corresponding serial port.
Enabled
The serial port is set to the indicated address and interrupt. If you select Enabled,
additional lines are displayed for the configuration settings.
Disabled
The serial port is disabled.
Auto
The serial interface will be selected automatically by the BIOS or operating system.
Parallel port (system-de pendent)
Sets the address and interrupt for access to the parallel port.
Enabled
The parallel port is set to the address and the interrupt shown here. If Enabled is
selected, additional lines are displayed for setting the configuration.
Auto
The parallel port is automatically set t o the next available combination (address,
interrupt).
Disabled
The parallel port is disabled.
20 Fujitsu Technology Solutions
