Interfaces and connectors
The location of the interfaces and connectors of your mainboard is specified
at the b eginning of the manual.
The c omponents and connectors marked are not necessarily presen t on the mainboard.
External p orts
The location of the external connections of your mainboard is specified at the beginning of the manual.
LAN port (RJ-45) USB 2.0 – Universal Serial Bus, black
Microphone/Audio input (Line in), light
blue
USB 3.0 – Universal Serial Bus, blue
(only D 3183)
Headphones/Audio output (Line out),
light green
HDMI (only D3173)
Serial interfa ce, turquoise
DVI–I
+
+
DisplayPort (only D3183)
