Fujitsu D3441 - Page 5

Internal connectors and slots
External connectors rear
Front panel
PS2
USB 2.0
COM /
DVI-D
CPU
USB 3.0
LAN2
USB 3.0
LAN1
Audio
Audio
Frontpanel
S/PDIF
FAN2
SLOT3 x1 + EDP
SLOT4 x1
SLOT2 x4
SLOT1 x16
FAN3
INTR USB 2.0
Label
SATA4 SATA5
SATA3 SATA1
SATA2
USB 3.0
ATX POWER
Front panel
+12V
MCARD
FAN1
Buzzer
PC98
COM2
SATA0
FAN4
Battery
USB 2.0
LPT
Display
Port
D3441-S
GPIO
Recovery inserted = The system starts
from USB stick and allows a BIOS recovery.
Details can be found in the BIOS manual.
1
2
HD-LED
Recovery
Reset
Power
On/Off
Power LED
Fujitsu
