¢ Others
Damper motor and cable (locally purchased)
Model name UTY-CDPXZC UTY-CDPXZD
Damper motor
Voltage AC24 V AC240 V
Frequency Hz 50
Maximum operating
current(per a damper)
mA 360 or less 70 or less
Maximum electric power
(per a damper)
VA 7 or less 12 or less
Damper motor
cable
Wire diameter
mm
2
0.48 or more 0.75
Type
RJ12
6-polar, 6-core
Type 60227
IEC52 or 53
Transformer (locally purchased)
Transformer Specification
UTY-CDPXZC (24 V) Select an appropriate transformer for the damper specification.
