5. Wiring design
5-1. System diagram
Indoor unit
Zone control interface
Outdoor unit
WLAN adapter
A
Prohibited uses:
(1) Combined use with wired remote controller
Zone control
interface
All wired remote
controller
(2) Extended wiring
Extending the cable is prohibited.
Junction box
Zone control
interface
- 41 -
ZONE CTRL SYSTEM with WLAN ADAPTER
