Fujitsu FO2416RTJNAA - Page 7

7
3.0 UNIT SPECIFICATIONS
Specifications
3.3 Electrical and Physical Data
Factory
Charge Minimum
Per Circuit Circuit
Regional
Standard
Statement
oz. (g) RLA LRA FLA HP Ampacity MAX MIN High Low
Mfr. Part No.
Codes
Model Number
(A)
(P)
Volts
(B)
Phase
(C)
Hertz
(D)
(E) (F) (G) (H) (J) (K) (L) (M) (N) (**)
(S)
FO2416RTJNAA
137 (3884) 208/230 1 60 13.0/13.0 58.3 2.8 1/3 20/20 30/30 25/25 550 (3792) 250 (1723) COPELAND 55-23156-47 9195 None
FO3616RTJNAA 156 (4423) 208/230 1 60 17.0/17.0 83 2.8 1/3 25/25 40/40 30/30 550 (3792) 250 (1723) COPELAND 55-23156-36 9196 None
FO4816RTJNAA 196 (5557) 208/230 1 60 23.6/23.6 104 1.4 1/4 31/31 50/50 40/40 550 (3792) 250 (1723) COPELAND 55-23156-37 9197 None
FO6016RTJNAA
242 (6861) 208/230 1 60 28.8/28.8 152.9 1.4 1/4 38/38 60/60 45/45 550 (3792) 250 (1723) COPELAND 55-23156-34 9198 None
Compressor Fan Motor
Compressor
Circuit Breaker Size
Fuse or HACR
PSIG (kPa)
Design Pressure
DIMENSIONALS
2-STAGE 16 SEER
HEAT PUMP
24 36 48, 60
31 (787) 35 (889) 45 (1143)
33.75 (857) 33.75 (857) 35.75 (908)
33.75 (857) 33.75 (857) 35.75 (908)
Height “H” inches (mm)
Length “L” inches (mm)
Width “W” inches (mm)
AIR INLET LOUVERS ALLOW
6” [152mm] Min. OF CLEARANCE ALL SIDES
12” [305mm] RECCOMMENDED
SERVICE PANELS/
INLET CONNECTIONS / HIGH & LOW
VOLTAGE ACCESS
ALLOW 24” [ 610 mm] OF CLEARANCE
ST-A1226-23-00
“H”
“W”
A
I
R
D
I
S
C
H
A
R
G
E
“L”
ALLOW 60" [1524mm] OF
CLEARANCE
SERVICE PANELS/
INLET CONNECTIONS /
HIGH & LOW VOLTAGE
ACCESS ALLOW
24" [610 mm] OF
CLEARANCE
AIR INLET LOUVERS ALLOW
6" [152 mm] OF CLEARANCE ALL SIDES
12" [305 mm] RECOMMENDED
NOTE: Actual unit
appearance may vary.
