Fujitsu General ASHG07KPCE

Item no. Part no. Part name Service part
50 9333897028 Evaporator total assy ♦
51 9387467017 Room thermistor holder ♦
52 9333865003 Box shield ♦
53 9901013010 Terminal ♦
54 9900627065 Thermistor assy ♦
55
9711141040 Main PCB (for 07 model) ♦
9711141057 Main PCB (for 09 model) ♦
9711141064 Main PCB (for 12 model) ♦
56 9334049006 Cable guide ♦
57 9711146021 Display assy ♦
58 9711147028 Indicator PCB ♦
59 9383765018 WLAN adapter holder assy ♦
60 9383729041 Wire cover assy ♦
61 9334040003 Motor case assy ♦
62 9603688004 DC fan motor ♦
63 9333849003 Motor cover assy ♦
64 9901011030 Step motor ♦
65 9333911007 Drain pan total assy ♦
66 9316904002 Drain hose assy ♦
67 9316177017 Drain cap ♦
68 9333628004 Bearing D assy ♦
69 9333606026 Crossflow fan assy ♦
70 9333882031 Base assy ♦
71 9334137000 Screw cap ♦
72 9334136003 Under cover C ♦
73 9388139012 Pipe bracket A ♦
a — Control box —
b — Control cover —
c — Display case assy —
2-1. Models: ASHG07KPCE, ASHG09KPCE, and ASHG12KPCE - (02-5) - 2. Indoor unit parts list
