Fujitsu General ASHG09KMCDN - Dimensions; Models: ASHG09 KMCDN, ASHG12 KMCDN, and ASHG14 KMCDN

2. Dimensions
2-1. Models: ASHG09KMCDN, ASHG12KMCDN, and
ASHG14KMCDN
Unit: mm
834
(834)
Outline of indoor unit
327
273273 54
215
3.0
270(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
- 4 -
2-1. Models: ASHG09KMCDN, ASHG12KMCDN, and ASHG14KMCDN 2. Dimensions
WALL MOUNTED ASHG09-14KMCDN WALL MOUNTED ASHG09-14KMCDN
