TX100 S1 Options Guide 39
Completion Closing the server
Installing the side cover
Figure 20: Installing the side cover
Ê Replace the side cover.
Ê Press the locking lever down until it clicks into place.
Ê Put the server back into the upright position.
Ê Connect all cables on the rear of the server.
Ê Connect the power plug to the grounded shockproof socket..
Ê Press the On/Off button to start up the server.
