Fujitsu PRIMERGY TX2540 M1

28 Operating Manual TX2540 M1
Functional overview
Onboard or integrated controllers
RAID Controller RAID 5/6 Ctrl., HDD SAS 6 Gb, LSI, 8 ports ext.
RAID level: 0, 1, 10, 5, 50, 6, 60; 512 MB Cache;
Optional BBU (based on LSI SAS2108).
Integrated RAID 5/6 Ctrl., HDD SAS 6 Gb, Fujitsu,
8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60; 1024 MB Cache,
Optional FBU (based on LSI SAS2208).
Integrated RAID 5/6 Ctrl., HDD SAS 6 Gb, Fujitsu,
8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache,
Optional BBU (based on LSI SAS2108).
Integrated RAID 0/1 Ctrl., SAS/SATA 6 Gb, Fujitsu,
8 ports int.
RAID level: 0, 1, 10, No BBU support (based on LSI
SAS2008).
RAID 5/6 Ctrl., HDD SAS 6 Gb, LSI, 8 ports ext.
RAID level: 0, 1, 10, 5, 50, 6, 60; 1024 MB Cache;
Optional FBU (based on LSI SAS2208).
SATA / SAS RAID
Controller
Intel C602, 6-port SATA (4x for internal HDDs, 2x for
accessible drives). On board SATA controller
supports RAID levels 0, 1, 10.
With SAS enabling key (optional): 4 x internal SAS
HDDs or 1x SAS backup drive; supports RAID levels
0, 1, 10.
LAN Controller Ethernet Controller Intel
®
i210 AT, 2 x 10/100/1000
Base-T
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4, 32 MB attached memory incl. graphics
controller), IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon TCG V1.2 compliant (option)
