32 Operating Manual
TX2540 M1
Functional overview
Electrical values
Screen resolution
The screen resolutions in the following table refer to the graphics controller on
the system board. The graphics controller is integrated in the iRMC (integrated
Remote Management Controller).
Power supply
configuration
1 x standard power supply unit (PSU) or 1 x hot-plug
PSU or 2 x hot-plug PSU for redundancy
Max. output standard
PSU
800 W (90% efficiency)
Max. output hot-plug
PSU
2x 450 W or 2x800 W (94% efficiency)
or 2x 800 W (96% efficiency)
Rated voltage range 100 V - 240 V
Rated frequency range 47 Hz - 63 Hz
Rated current 7.6 A - 3.7 A / 100 V - 240 V
Current
(basic configuration)
0.7 A - 0.3 A / 100 V - 240 V
Current
(max. configuration)
4.4 A - 1.8 A/ 100 V - 240 V
Apparent power 435 VA
Effective power 432 W
Heat dissipation 1555 kJ/h (1474 Btu/h)
Screen resolution
(pixel)
Maximum refresh
rate (Hz)
Max. number of colours
640x480 85 32 bit
800x600 85 32 bit
1024x768 75 32 bit
1152x864 60 16 bit
1280x1024 60 24 bit
1600x1200 60 16 bit
1920x1080 60 16 bit
