TX2540 M1
Operating Manual 57
Hardware installation
Two additional USB connectors (1) are located on the front of the server
(figure 3):
Figure 3: Front side connectors
I If components with large power requirements (e.g. external USB hard
disk drives) are connected simultaneously, these USB connectors may
be switched off.
Connecting the keyboard, mouse and monitor
Ê Connect the monitor, the keyboard and the mouse to the standard ports of
the server (see figure 2 on page 56).
Ê Connect the power cable of the monitor to a grounded mains outlet of the in-
house mains and/or to the mains socket strip of the rack.
V CAUTION!
The rated current for the monitor is indicated on the technical data label
on the monitor or in the operating manual for the monitor.
햲
