Fujitsu ScanSnap S1500 Installation & Troubleshooting Guide

If you have installed the software before
22
6. Click the [ScanSnap] button.
Example: [Install Products] dialog box for S1500
 The [ScanSnap] dialog box appears, displaying the [Welcome to the InstallShield
Wizard for ScanSnap] screen. Follow the instructions on the screen to continue with
the installation.
If you did not perform the procedure in "Removing the installation information" and then failed to install
the software, perform the following procedures again:
- "Uninstalling the software" (page 12)
- "Removing the installation information" (page 16)
- "Installing the software from the [ScanSnap Setup] dialog box" (page 20)
If you still could not reinstall the software after performing the above procedures, proceed to "Installing
one software at a time" (page 23).

Fujitsu ScanSnap S1500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
Bundled software	ScanSnap Organizer V4.0, CardMinder V4.0, Adobe Acrobat 9 Standard, ABBYY FineReader
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 159 x 158 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.5 x 6.3 x 6.2 \
Sustainability certificates	ENERGY STAR
Power consumption (standby)	4.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	3000 g
